STS ATM.1ST/Ex High Precision Pressure Transmitter
High-precision pressure transmitter family with ATEX/IECEx options, nominal pressure range 50 mbar–1000 bar and selectable precision class up to ±0.05% FS. Check certified variant, safety instructions, gas group, temperature class and exact connection before Ex-zone use.
Manufacturer documentation and verification
Official ATM.1ST/Ex product page and technical downloads →
Product-level QA: This entry documents the verified manufacturer family, not every current SKU. Orderable electrical and mechanical variants, exact certificate schedule and a manufacturer-source model photograph remain subject to individual review. Never treat a family name as universal hazardous-area approval.
Certification scope
STS lists ATM.1ST/Ex as an ATEX/IECEx-certified high-precision pressure transmitter family, with pressure measuring range 50 mbar–1000 bar and selectable ±0.10% / ±0.05% FS accuracy. The manufacturer’s ABS approval for ATM.1ST/Ex cites ATEX certificate SEV 09 ATEX 0108X and IECEx certificates IECEx SEV 10.0003X and IECEx MSC 14.0002X. Connection type changes protection grouping: only specified screened cable or metallic plug configurations are identified for IIC Ga in the cited certificate; other versions are described as IIB Gb. The installed unit’s nameplate and certificate schedule take precedence.
Manufacturer-hosted ABS certificate with Ex reference numbers · Original Ex certificates
Manufacturer-verified technical facts
Manufacturer specifications: 50 mbar–1000 bar range; selectable ±0.10% / ±0.05% FS accuracy; −40 to +125°C operating temperature; 4–20 mA output; stainless steel or titanium. STS lists ATEX and IECEx certificates. Do not extrapolate an approval to an unlisted electrical connector or order code.
Manufacturer catalog and certificates
Verified IECEx certificate scope
ATM.1ST/Ex — IECEx SEV 10.0003X, issue 3 (24 January 2018). The official IECEx schedule covers ATM.1ST/Ex pressure transmitters explicitly. Different process-connection, electrical and cable variants may have different permitted gas groups and installation conditions; titanium housing must be protected from friction and mechanical spark risk as the certificate states. Do not extrapolate approval to ATM.1ST without /Ex suffix.
Official IECEx schedule covering ATM.1ST/Ex · Installation safety instructions.
ATM.1ST/Ex — process and electrical limits
| Selection point | Model-specific evidence |
|---|---|
| Available nominal spans | 0–50 mbar through 0–1000 bar; barometric and negative-pressure options. |
| Static accuracy / thermal band | ≤±0.10% or ±0.05% FS; total error ≤±0.15% FS over 0…70°C. |
| Operating versus process temperature | Overview: −40…125°C operating; −40…150°C process. Neither overrides certified ambient limits. |
| Output | 4–20 mA for this /Ex overview; do not inherit standard-model voltage options. |
| Construction | Stainless steel or titanium, selected for media compatibility. |
Treat the high-temperature process option and hazardous-area ambient rating as separate selection checks. Locate the electronics where both requirements are satisfied. An instrument selected for a high full-scale range can have substantial absolute uncertainty at low readings; select the span for the measurement rather than simply the maximum pressure encountered.
STS model documentation. Technical source review: 26 October 2026.
